BAPS Hindu Mandir in Abu Dhabi from Lynx Pro Audio

Oct 24, 2024 | Houses of Worship, Installations, Houses of Worship

The BAPS Hindu Mandir in Abu Dhabi (UAE) is a project undertaken by BAPS Swaminarayan Sanstha and Lynx Pro Audio technology.

The BAPS Hindu Mandir in Abu Dhabi (UAE), is a traditional Hindu mandir built by the BAPS Swaminarayan Sanstha. Inspired by Pramukh Swami Maharaj (1921–2016) and consecrated by Mahant Swami Maharaj on 14 February 2024, this is the first traditional Hindu mandir in Abu Dhabi.

In August 2015, the UAE government announced they would provide the land for the mandir. Sheikh Mohammed bin Zayed Al Nahyan, the Crown Prince of Abu Dhabi, gifted 27 acres of land for the mandir.

The challenge of acoustically equipping a sacred space such as the BAPS Hindu Mandir in Abu Dhabi was one that Lynx Pro Audio masterfully addressed. Opened on 14 February 2024, this first traditional Hindu mandir in Abu Dhabi required a sound system that respected the ancient architecture while offering an immersive listening experience. The solution, a combination of precise acoustic design and state-of-the-art audio technology, has resulted in a space where sound becomes a unifying element between the spiritual and the technical.

The main auditorium of the BAPS Hindu Mandir is equipped with a powerful and advanced sound system to ensure crystal-clear audio for large gatherings and events.

– CLS-212 Array: Provides dynamic and immersive sound for the main auditorium.

– CLS-218S and CLS-118S Subwoofers: Deliver deep bass that complements the main audio array, enriching the auditory experience.

Strategically placed audio units ensure that both the exterior and interior spaces of the temple are enveloped in high-quality sound, creating a serene and immersive environment.

– Over 200 Ionic-5CXV Units: These units are installed to welcome visitors with traditional soothing sounds outside and enhance the acoustic ambiance inside various rooms.

A comprehensive range of audio equipment has been installed throughout the mandir complex to ensure consistent and superior sound quality across all areas.

– JN-6T and JN-8WT Cabinets: Versatile audio solutions for different spaces within the mandir.

– WCX-8, IONIC-100/OD, and QB-5W Speakers: Ensure uniform sound distribution throughout the complex.

– SUB-08W and GTX Series Amplifiers: Provide robust amplification, enhancing the overall audio experience.

– IXP-4 and IXP-6 Ceiling Speakers: Over 400 units installed for seamless audio coverage.

Construction process

– Legalisation and Commencement: In September 2019, the mandir gained legal status and construction commenced in December 2019.

– Materials and Dimensions: Constructed from pink sandstone from northern Rajasthan and marble from Italy, the mandir stands 108 feet tall, 262 feet long, and 180 feet wide.

– Volunteer Contribution: Over 200 volunteers from various countries dedicated more than 690,000 hours towards the construction.

This is the first Hindu stone mandir to undergo complete digital modeling and seismic simulations during the construction process. The mandir is a symbol of interfaith harmony, representing the UAE’s and India’s good relations to foster understanding, acceptance, and unity among people of different religious backgrounds.

Accordingly, the mandir carvings not only incorporate stories from the Ramayana, Shiva Purana, Bhagavatam, Mahabharata, and the lives of Hindu figures, but also stories from Arabian, Egyptian, Mesopotamian, Native American, and other civilizations.

Multifunctional spaces

The BAPS Hindu Mandir complex includes a variety of facilities, each benefiting from the advanced audio technology installed throughout.

– Traditional Hindu Mandir: A serene space for worship, enhanced by superior audio quality.

– Visitor Centre and Prayer Halls: Equipped with state-of-the-art sound systems for informative and meditative experiences.

– Exhibition and Learning Areas: Facilitated by clear and engaging audio presentations.

– Children’s Sports Area and Thematic Gardens: Background music and announcements delivered through high-quality speakers.

– Food Court and Gift Shop: Enjoy a pleasant atmosphere with ambient sound.

Explore our blog for more detailed articles on the integration of advanced audio systems in sacred spaces worldwide. Stay updated about the lastest projects!

Sound installation at Rock Bar, Bali

Jun 5, 2024 | Internacional, Nightclubs & Bars, Our Clients, Restaurantes

Known as “Bali’s Most Popular Sunset Bar,” Rock Bar Bali is not just a bar, it’s a complete sensory experience. Renowned for the mastery of its bartenders, this iconic spot will captivate you with magical sunsets, vibrant music and an electrifying atmosphere.

Located at the AYANA Resort and Spa, Rock Bar Bali is perched on a 14m limestone cliff, offering a 180-degree panoramic view. Imagine the waves crashing against the rocks, the radiant sun about to dip into the Indian Ocean and Jimbaran Bay bathed in a golden light. A natural light show that will take your breath away.

This unique space is characterized by a minimalist design that seamlessly integrates an open platform into the natural formation itself. The ambient lighting of the bar, together with the sunset curtains and traditional lanterns of the fishing boats that dot the horizon, create a unique and unrepeatable atmosphere.

The combination of exclusive cocktails, exceptional views and an electrifying atmosphere created by its resident DJ and an occasional programming of world-class international artists, make this bar one of the best in the world in its category.

MONDO-DR.

The distributor Melodia, together with its partner AV Sontastic, were the companies in charge of ensuring the correct distribution and calibration of the sound throughout the area using the most suitable coatings. The installation was a challenge given the exceptional conditions of the open-air site, extended along the edge of a cliff 14 metres above sea level.

Given the particularities of the installation, Melodia and Sontastic decided to install all sound systems in a weatherproof version, an option offered by Lynx Pro Audio for extreme installations of this type, where venues need special protection designed to withstand extreme weather conditions, such as sunlight, salt and water.

Eight WCX-8 compact speakers have been installed along the bar, a versatile and modular two-way coaxial enclosure designed for outdoor applications. It has an 8″ coaxial speaker offering a 70º conical dispersion coverage and a power of 300 W AES. As reinforcement for different areas, 7 two-way HR-1596/7 enclosures have been installed, a full-range system with a power of 700 W AES. It has a wide coverage of 90×60º and a passive/bi-amplified selector, mounting a 15″ speaker together with a 1.4″ driver and a rotatable horn that allows you to choose the most suitable coverage angle according to the installation.

To reinforce the low frequencies, three HR-218/12 high-performance passive subwoofers have been installed, with two 18″ speakers in direct radiation low-reflex configuration.

With omnidirectional coverage and 1200W AES power, the weatherproof products have specific features for greater outdoor durability and to withstand harsher weather conditions: anodized aluminum logo for better durability, stainless steel grill also available in aluminum with protective coating and micro-textured paint, weather tape edges, acustex filter to prevent water and external elements from penetrating, 35 ppi acoustic foam to prevent dust particles from affecting internal components, waterproof cone protected on both sides, aluminum back plate with pressure gland for extra tight connection and stainless steel screws.

To amplify the sound, five Lynx Pro Audio TS series amplifiers have been installed on the south and north sides of the venue. These are high performance 4 channel mid/high power power amplifiers dedicated to the installation market capable of meeting the requirements of any installation from 300 to 2500W. Sontastic said: “A well designed audio system should cater to a variety of musical preferences.

Rock Bar Bali, nominated as one of the best hotel bars in the world, it is distinguished by its exclusivity and exceptional atmosphere, positioning it as an incomparable oasis.

Sound revamped at the Valencia Oceanographic aquarium with CXA-12 for outdoors

May 14, 2024 | Installations, Public Buildings

Oceanogràfic, the biggest aquarium of Europe, has recently renewed its sound equipment in the dolphinarium area, trusting once again in Lynx Pro Audio. 15 outdoor passive CXA-12 enclosures have been set up in the venue, supplied by Neec Iberia, the official distributor of the brand in Spain and Portugal.

Until now, this dolphinarium had a set-up of Ionic-100 column speakers distributed around the pool, in front of the stands, to improve vocal clarity; while several DRN-12 subwoofers were flown to reinforce the low frequencies.

From now on, 15 units of passive CXA-12 speakers suitable for outdoor use will be covering the sound of the dolphinarium, next to the columns of the stands. The CXA-12 is a constant curvature line array, designed to make basic multipurpose line array configurations, with a maximum of four cabinets.

These 15 cabinets have been distributed in 3 points with three cabinets in array configuration and another 3 points with two cabinets, with the aim of covering the extensive stands with clarity and power, so that both the explanations of the monitors and the music can be heard clearly in each performance.

Each CXA-12 enclosure is amplified with a total of 1400 W Class D and switching power supply, with a PFC system and DSP processor with linear phase FIR filters.

For the amplification of the cabinets, 3 XT-10K amplifiers (4-channel stage for installation with 4 x 25000W of power, 64-bit DSP and Networking AES67 connectivity option), a RS4-3000 amplifier (4-channel stage with power up to 500 W per channel and connectivity through 4 balanced XLR inputs) and a RS4-4000 amplifier (4-channel amplifier with power up to 1000 W per channel and connectivity through 4 balanced XLR inputs) have been set up.

Finally, ARK digital processors have been implemented, specifically an ARK-2026 (2 inputs and 6 outputs) and an ARK-7048 (with Ethernet, 4 inputs and 8 outputs) designed to offer intuitive and easy-to-use access for users.

Baptist church sound reinforcement upgraded in Nordhorn, Germany

Jun 8, 2023 | Houses of Worship, Installations, Our Clients

The Baptistenkirche Nordhorn, as its German name suggests, is a Baptist church located in Nordhorn, Germany. Tom Fuhrmann, Pro Audio consultant in Pan-pro GmbH, has been in charge of the church sound reinforcement.

Baptistenkirche Nordhorn is a religious community that aims to help others to know Jesus, to be inspired by him and to increase their faith in him. It is a community committed to the well-being of the people of its city.

The church needed to upgrade its sound systems for a clear voice reproduction and the installer decided to set up IONIC column speakers, which are designed for reverberant installations such as houses of worship. These column speakers are lightweighted, providing easy set ups in fixed installations.

The installer chose the following set-up: 3 x IONIC 100 for main area, 7 x IONIC 50 for senior space and under balcony, 1 x IONIC 18S all feeded by Yamaha MTX5D and RS4-4000 amplifiers.

Tom Fuhrmann stated: “It has been found that the IONIC series from Lynx Pro Audio delivers excellent results, specially in acoustically demanding rooms. Significantly improved speech intelligibility and a balanced sound image were decisive for the customer’s satisfaction.”

In white colour, these cabinets are a low profile, discreet column, melting in the church’s white environment. Fuhrmann stated that the customers “are happy with installation”.

In the main area we find 3 Ionic-100 passive column speakers. The Ionic-100 uses 12 x 3″ (0.75″ voice coil) neodymium transducers offering a coverage of 15º +/-5º V x 100º H and 121dB SPL.

For senior space and under balcony we find 7 Ionic-50 passive column speakers. The Ionic-50 is a compact column speaker with 6 x 3” (0.75” voice coil) neodymium transducers offering a coverage of 15º +/-5º V x 100º H and 119dB SPL.

As low frequency reinforcement, we find the powered subwoofer Ionic-18S. This subwoofer uses 1 x 18” (3” voice coil) neodymium transducers with 132 dB SPL.

The installation was feeded by an RS4-4000 amplifier, designed for professionals who demand quality, reliability and value.

The Ionic series are available in a variety of colours/finishes by request, in this case, white RAL colour. As standard the full-range cabinets are finished in anti-rust steel and the subs in rugged, premium birch plywood, coated with polyurea paint. All are protected by front steel grills and backed with a special triple layer, acoustic textile which allows greater air flow and reduces heat and humidity.

Set-up details:

3 x IONIC 100 for main area
7 x IONIC 50 for senior space and under balcony
1 x IONIC 18S
RS4-4000 amplifier

Ionic-100

Ultra-compact, passive column speaker with 12 x 3″ (0.75″ voice coil) neodymium transducers. 15º +/ -5º vertical coverage. 121dB SPL.

More details

Ionic-50

Ultra-compact, passive column speaker. Consists of 6 x 3” (0.75” voice coil) neodymium transducers. 15º +/- 5º vertical coverage. 119dB SPL

More details

Ionic-18S

Ultra-compact, self powered (class D switch mode power supply with PFC), omni-directional subwoofer cabinet.

More details

RS4-4000

RS amplifiers represent the best compromise between economy and performances, taking advantage of latest improvements in electronic assembly.

More details

More installations

Juno series at Mamaka Hotel in Bali, Indonesia

Bali seems to be the perfect place for our weather-resistant small enclosures Juno series. Our Indonesian distributor (Melodia) and their AV consultant partner Sontastic have been tasked with installing the Mamaka Hotel…

Read more

La Diva, a chic restaurant inspired by the 20s

Entering La Diva is like going back in time to the roaring 20s. The objective of the restaurant is to make you feel like a Diva, In this restaurant, the sound system is key…

Read more

Restaurant JP 1886, former Verkade factory in Amsterdam

JP 1886, is a restaurant and event location in a monumental building, the former Verkade factory, situated on the river Zaan..

Read more

Bali club Mrs Sippy main stage revamped with DS-12 clubbing systems

May 16, 2023 | Installations, Nightclubs & Bars, Our Clients

Mrs Sippy, a trendy party venue on the island of Bali, has decided to do an image renovation and update its main stage with Lynx Pro Audio sound systems for nightclubs: the DS-12 enclosures.

Host to the island’s biggest saltwater swimming pool with 1, 3 and 5 meter diving platforms, good times are encouraged through their entertainment calendar of international DJ’s spinning tropical island vibes until late every day.

Sontastic, a premier AV installer specialising in integrating systems for beach clubs, restaurantes and hospitality business, has been in charge of the renewal of Mrs. Sippy’s main stage. They have decided to acquire Lynx Pro Audio’s special clubbing systems, supported by Melodia, official distributor in Indonesia.

Ian Johansson, Sontastic’s director, stated: “Sontastic have been using DS-12 for four years now, and we are very happy with this speakers. It has the emotion of a classic club speaker but is more smooth and versatile. When paired with the right amplifier, the DS-12 plays absolutely fantastic! We are getting a lot of compliments for this setup and very happy with the Lynx.”

Lynx Pro Audio’s DS systems were required for the upgraded main stage that has been set up near the pool, where parties are organised everyday and international DJs come to play on weekends. The stage set up cointains 3 DS-12 cabinets on each side of the stage for a powerful result.

These sound systems are available in any colour and finish needed, since they are not designed to not only be pleasing to the ear but also to the eye.

The horn loaded, high power DS-12 clubbing systems are ideal for these installations since they were primarily designed for giving an extra boost in nightclubs and discos. The cabinet is bi-amplified and can also be manufactured as a self-powered version to deliver all the features such as FIR that Lynx Pro audio electronics deliver.

It uses an exponential 12” Driver (64mm aluminium voice coil) for the low/mid and the high frequencies are looked after by a 1.4” neodymium compression driver with titanium diaphragm and mylar surround. The special GFK/Sandwich horn delivers 60º x 40º coverage.

Mrs Sippy Bali is the latest holiday hotspot, a melting pot for locals and international travellers who occupy the abundance of day beds while sipping expertly shaken cocktails.

DS-12

High output, hornloaded, two-way cabinet. Consists of a 12″ (64mm aluminium voice coil) transducer and a 1.4″ neodymium compression driver. 60º x 40º horn. 133 dB SPL.
