CPS-14P (64 / 96)
Bi-amplified coaxial point source
Two models: CPS-14P/64 & CPS-14P/96
Extremely compact & powerful 3-way, bi-amplified coaxial point source element. High power 14″ neodymium transducer and a unique 1.4″ exit dual diaphgram coaxial driver.
Two models depending on coverage: CPS-14P/64 (60ºH x 40ºV) or CPS-14P/96 (90ºH x 60ºV).
Description
The CPS-14P is a high-output extremely compact and extremely powerful 3-way, bi-amplified DSP integrated, symmetrical Coaxial Point Source element designed for touring & fixed installations.
It uses one low distortion 14″ (4″ DUO double layer voice coil) custom speaker for the low frequencies with exclusive Malt Cross cooling technology, FEA optimized neodymium magnet circuit, aluminium demodulating ring and weatherproof cone.
For the mid/high frequencies it uses an ultra light weight 1.4″ dual diaphragm coaxial compression driver. The unique voice coil technology employs a light weight copper clad aluminium wire, wound inside and out of the Kapton former to improve heat dissipation, dramatically increasing the acoustic output and reliability of the driver while minimizes the power compression.
The larger annular midrange diaphragm covers the frequency range between 300Hz and 7KHz with a smooth, linear response. The ultra light annular diaphragm for the high frequencies offers exceptional transient response with very high efficiency from 4KHz to 22KHz.
With two subsystems in one each driver covers a smaller frequency range for increased power handling, high dynamic and extremely low distortion and delivers excellent phase coherence & perfect time alignment without problems of multi-source interference.
The enclosure is made from premium grade birch plywood and finished with a polyurea coating for longer durability & weather protection.
Perfectly suited for:
| → Outdoor events | |
| → Medium sized stadiums / arenas | |
| → Auditoriums | |
| → Houses of worship | |
| → Theatres | |
| → Clubs |
Key features
|
→ Extraordinary power-to-size ratio |
|
→ Three way bi-amplified system |
|
→ 1.4” exit dual diaphragm coaxial driver |
|
→ Ergonomic design in premium birch plywood & finished in polyurea |
Technical Data
Components |
LF: 1 x 14” (4” voice coil), neodymium magnet |
1 x 1.4″ exit dual diaphgram coaxial driver.
|
|
| Frequency Range |
55 Hz – 22 KHz (-6dB) |
Coverage |
Rotatable 60ºH x 40ºV / 90ºH x 60ºV |
| Max SPL* |
Low: 130 dB / 136 dB peak |
Sensitivity |
LF: 100 dB
|
| Impedance |
Low section: 8 Ω |
Crossover |
Mid/high: 4500 Hz
|
| Speakon connection | NL4MP +1/-1 Low, +2/-2 Mid/High |
| Finish | Polyurea coating, high grade resistant paint |
Material |
15 mm premium birch plywood |
| Dimensions | 755 x 415 x 430 mm (H x W x D) |
Weight |
31 Kg (68.3 lbs) |
*Calculated maximum SPL based on rated peak power and measured sensitivity.
More features
Hardware for CPS-14P
 |
EnclosureThe CPS-14P cabinet is constructed from 11-ply premium birch plywood (15mm thickness) and finished with polyurea coating |
 |
Internal designThe internal structure of the CPS-14P is heavily braced for greater longevity and all parts are assembled on metal inserts with metric screws. |
 |
GrillThe CPS-14P has three heavy duty, powder coated front grille with a special acoustic rear fabric to protect the transducers against dust and dirt. The medium frequencies grille uses a magnetic attachment system that can be removed for easy access and rotation of the diffuser. |
 |
HandlesThe CPS-14P has two ergonomic handles with firm internal grip to facilitate transport, positioning and loading of the cabinets. Both handles are placed at the top and bottom of the cabinet. |
Accessories for CPS-14P
 |
AGR-10 Eye bolt for CPS-14 |
 |
SC-FC1 Lightweight install stud for CPS-14 |
 |
UBR-HCPS14 Horizontal U bracket for CPS-14 |
 |
UBR-VCPS14
Vertical U bracket for CPS-14
|
 |
FD-1CPS14NL Rain cover for CPS-14 |
 |
FD-CPS14 Nylon protection for CPS-14 |
 |
DI-1464C Rotatable horn for CPS-14P/64 |
|
DI-1496C Rotatable horn for CPS-14P/96 |
